Industrial robot manipulator CRP-RA09A-07(T3)

Application
Arm length (mm)
Load capacity (kg)

  • Axis 2 adopts directly connected structure to effectively improve accuracy;

  • Motor and reducer adopt spline connection to be more stable

  • Adopt customized structure to effectively avoid interference and meet the need of application in narrow space;

  • Compact structure and small volume

  • Light weight and fast speed

THE INTRODUCTION AND FEATURES OF ELECTRICAL CABINET​​​

​

  • CRP-RA09A-07 T3  is  mainly  customized  for  the  production  and  application  of PCB board industry. It is  applied  in  the  loading  and  unloading  process  of  PCB board industry. In order to adapt to the PCB industry, CRP robot with light weight, simple application, high speed and lower cost is launched to meet the needs of customers for robots.

CRP-RA09A-07(T3) Motion Range Diagram
CRP-RA09A-07(T3) Motion Range Diagram
Download Robot Catalog
CRP-RA09A-07(T3)
